DETAILS
Type of panels : NUUKO PERC Technology Half-Cut Cells * Bifacial * Single-Glass*Black Frame
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 530W-550W
Efficiency range : 20.53%-21.31%
Dimensions : 2278 mm x 1134 mm x 30/35 mm
Weight : 27 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years

DETAILS
Type of panels : NUUKO PERC Technology Half-Cut Cells * Bifacial * Single-Glass*
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 435W-455W
Efficiency range : 20.00%-20.90%
Dimensions : 2094*1038*35mm
Weight : 23 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years

DETAILS

Type of panels : NUUKO PERC Technology, Half-Cut Cells * Bifacial * Double-Glass*
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 435W-455W
Efficiency range : 20.0%-20.9%
Dimensions :2094*1038*35mm
Weight : 26.5 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Back Glass: 2.0mm (0.08 inches) Glazed Semi-tempered Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years

DETAILS
Type of panels : NUUKO PERC Technology Half-Cut Cells * Bifacial * Single-Glass*Black Frame
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 435W-455W
Efficiency range : 20.0%-20.9%
Dimensions : 2094 mm x 1038 mm x 35 mm
Weight : 23 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years

DETAILS
Type of panels : NUUKO PERC Technology Half-Cut Cells * Bifacial * TRANSPARENT BACKSHEET*
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 530W-550W
Efficiency range : 20.53%-21.31%
Dimensions : 2278 mm x 1134 mm x 30/35 mm
Weight : 27 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years

DETAILS
Type of panels : NUUKO PERC Technology Half-Cut Cells * Bifacial * TRANSPARENT BACKSHEET*
Type and no. of cell : Mono-crystalline 144 (6x12)
Maximum system voltage : 1500 (V)
Power range : 435W-455W
Efficiency range : 19.8%-20.7%
Dimensions : 2094*1038*35mm
Weight : 22 kg
Frame:Anodized Aluminum Alloy
Front Glass:3.2mm Tempered Low Iron Glass
Junction box:IP68
Connector:MC4
Cables:Portrait 300mm/Landscape 1200mm/Customized
Performance Guarantee : 25 years
Product Warranty : 15 years
